VDWALL LVP605 Series Video Processor with Linsn or NovaStar Sending Card

Features

The VDWALL LVP605 Series Video Processor is a powerful and flexible LED wall controller designed for professional live event production. It supports seamless video switching, real-time enhancements, and multi-format signal inputs, making it ideal for concerts, conferences, trade shows, and large-scale presentations.

Engineered with Faroudja® DCDi Cinema Processing, RealColor®, and TrueLife™ Video Enhancer technologies, this processor delivers brilliant image quality with precise scaling and color accuracy. With a wide range of input options and custom PIP/POP modes, the LVP605 can handle the most demanding display requirements with ease.

Compatible with Linsn or NovaStar sending cards, this model offers built-in support for LED transmission, making it an excellent all-in-one processor and sender solution.

Technical Specifications

• Processing Technology:

  • 10-bit Faroudja® DCDi Cinema Processing

  • RealColor® & TrueLife™ Video Enhancement

  • 4x4 pixel interpolation scaling algorithm

• Video Inputs (10 Channels):

  • 3 × CVBS (Composite Video)

  • 1 × DVI

  • 1 × HDMI 1.3a with HDCP (Supports 1080P)

  • 2 × VGA

  • 1 × YPbPr / YCbCr

  • 1 × S-Video

  • 1 × EXT (Extended module: SDI / HD-SDI / 3G-SDI or VGA / DVI / HDMI depending on model)

• Audio Inputs:

  • DVI, HDMI, SDI embedded audio

  • 2 × external stereo audio inputs

  • 5-channel audio switching

• Video Outputs:

  • Resolutions: Up to 2304 × 1152 or 2560 × 816 per unit

  • Supports multi-unit parallel installation for unlimited pixel width

• Advanced Display Features:

  • Seamless switching between sources

  • Fade-in/Fade-out and Blend transitions

  • Picture Freeze

  • PIP/POP (4 customizable modes with one-touch switching)

  • Logo and text overlay

  • AIAO (Any In Any Out) for flexible zone mapping

• Control Options:

  • Front panel knob and key control

  • RS232 command support

  • Built-in hot spare functionality for stable operation

• LED Wall Support:

  • Built-in slots for 2 LED sending cards (Linsn or NovaStar supported)

  • Designed for 24/7 continuous operation

• Model Variants:

  • LVP605: Standard video processing

  • LVP605S: Adds SDI / HD-SDI / 3G-SDI support

  • LVP605D: Extended support for VGA / DVI / HDMI

Dimensions & Weight

• Rack Size: 1U standard

• Weight: Approx. 4.5 kg (9.9 lbs)

Application Scenarios

• LED Wall Video Switching for Concerts

• Large Corporate Events & Galas

• Conferences and Trade Shows

• Broadcast, Sports, and Political Events

• Fixed LED Display Installations

Package Includes

• (1) VDWALL LVP605 / LVP605S / LVP605D Video Processor

• (1) Power Cable

• (1) USB/RS232 Control Cable

• (1) Optional Linsn or NovaStar Sending Card (Installed Upon Request)

• (1) User Manual

• (1) Rugged Rental Transport Case (optional)

Why Choose VDWALL Video Processor for Your Event?

For precise control over live video feeds and dynamic LED wall visuals, the VDWALL LVP605 Series Video Processor is a top-tier choice. Its combination of seamless switching, PIP/POP layering, and broadcast-quality image enhancements ensures that your visuals stay crisp and engaging throughout your event.

With compatibility for Linsn or NovaStar LED control systems, it's ideal for rental applications and permanent installations alike. Whether you're managing multi-camera feeds at a concert or running sponsor loops at a corporate show, this processor delivers professional results every time.

We support full setup, delivery, and live operation assistance throughout New York, Philadelphia, Boston, Charlotte, Florida, and Washington DC—ensuring your visuals perform perfectly when it matters most.
